CW-CC 1/4″: Crossover Clamp For Messenger Wire

CW-CC 1/4″ Crossover Clamp for Messenger Wire

1. Product Overview

The CW-CC 1/4″ Crossover Clamp​ is designed for aerial construction​ applications. It is used at the mid-span​ to securely fasten two 1/4″ messenger strands​ together in a perpendicular (cross) configuration. This fitting is essential for maintaining the structural integrity and stability of overhead telecommunication and power lines.

2. Applications

• Overhead distribution and transmission lines

• Aerial fiber optic cable installations (ADSS & Figure‑8)

• Mid-span support for crossing messenger wires

• CATV, utility, and telecommunication infrastructure

3. Key Features & Benefits

• Integrated Tapped Plates:​ The clamp body is threaded, eliminating the need for loose nuts. This reduces installation time and prevents hardware loss during overhead work.

• Robust Construction:​ Consists of two heavy-duty 2‑3/8″ clamping plates for maximum grip and load distribution.

• Secure Fastening:​ Supplied with two high-strength 3/8‑16 × 1″ bolts​ for reliable locking.

• Superior Corrosion Resistance:​ Fully hot-dip galvanized to withstand harsh outdoor environments and ensure long-term durability.

• Easy Installation:​ Simple bolt-on design allows for quick assembly at the worksite.

4. Technical Specifications

5. Installation Note

Install the clamp at the intersection of two 1/4″ messenger wires. Ensure the bolts are torqued evenly to provide firm contact without damaging the strand surface. Suitable for use in both telecommunication and power utility projects.
